CloudSwitch MGLite 5

Cloud Managed 5-Port 2.5 Gigabit Switch (ECS205L)

Introduction

This Quick Start Guide is designed to guide you through the installation of the CloudSwitch MGLite 5, model ECS205L, including hardware installation and configuration.

CloudSwitch MGLite 5

Cloud Managed 5-Port 2.5 Gigabit Switch

Model: ECS205L

• 5 x 2.5G Ports to unleash elevated speeds for NAS, workstations or WiFi 6 APs.

Content Quick Links

Hardware Installation

Management Plane

Option A: Cloud Management

Option B: Standalone Configuration

Package Contents

System Requirements

To provide you with a better experience, we will continue to update the firmware. Please ensure that your firmware version is v1.0.1 or higher. Updated firmware files will be made available on the official website.

Web Browser:

• Google Chrome (57.0.2987.110 and later)

• Microsoft Edge (80.0.361.103 and later)

• Mozilla Firefox (52.0 and later)

Hardware Overview

Front Panel - Ports & Buttons

• Reset to default: Press and hold for over 10 seconds, and all ports LED will go off and on. Then the device will be reset to factory default settings.

Front Panel - System & Ports LEDs
