This session will assist you in setting up a new network on the EnGenius Cloud web application. For easier, faster setup, use the EnGenius Cloud for iOS or EnGenius Cloud for Android mobile apps. No matter which version you start with, you can always switch seamlessly between the web and mobile.

Before devices on EnGenius Cloud can be managed and configured, they must be added to a network that you have created.

Adding Devices to a Network

1. Navigate to Organization > Inventory.

2. Select one or multiple devices as required.

3. Click Assign to Network.

1. Check the LED Status to see if any problem encountered. If Power LED keeps flashing for over 10 minutes, then there could be Cloud connection issues.

2. Use your mobile phone to scan if Default SSID of the AP found. (you have to be around the AP location) From the Default SSID, you can also identify which stage the AP is stuck on. See details of Default SSID.

3. To troubleshoot the connection issue, you may login to Local page:

   1. Use your client device (e.g., a laptop, mobile device, or tablet) to find the SSID: “EnMGMTxxxx” (xxxx is the last four digits of LAN MAC which can be found on the back of the device) and connect to it.

   2. Enter the URL in web browser: http://EnGenius.local or the IP 192.168.1.1 to access the device’s user interface. You can review device status after logging into the AP with the default account/password ( default admin account/ password : admin/ admin.)

Issue: Cannot find Default SSID

1. Check for available wireless networks (Check if a known default SSID is being broadcast).

2. If a default SSID is being broadcast, connect your device to it.

3. If no known default SSIDs are present, set up a manual wireless network connection. For the SSID name, use 'EnMGMT', e.g. 'EnMGMTxxxx', where the x's are replaced with the last four digits of the LAN MAC address.

4. After connecting, open a web browser and connect to one of the local access page addresses.

ECW AP

ECS Switch

ECW AP Installation

ECW AP Package Contents

-ECW115

Minimum Access Requirement

Power source option - An ECW AP device can be powered by an 802.3af/at-compliant PoE device or by DC12V input

Ethernet port:

• LAN (PoE): Uplink port accepts an 802.3af/at power source.

• LAN2: Data link if this port is built on a device.

Connect the AP to Internet:

You need to find a way to let the Cloud AP be able to access internet, so it can be managed by EnGenius Cloud.

• Connect the uplink LAN port to a switch port or port of router: This is the most common way to let AP be able to access Internet. (Note: please make sure the port is internet accessible by connecting a notebook to the port and browse the internet)

• Use your existing Cloud-managed ECW AP to mesh the new AP: Sometimes the place the AP installed is not accessible with Ethernet cable, then you can leverage EnGenius Mesh technology to mesh the new AP to your existing cloud-managed ECW AP.

• After internet connected, you will see Power LED blinking until the AP is able to communicate with EnGenius Cloud and the LED becomes steady lid. Usually it will take about 8 mins if there is new firmware available to upgrade.

• If the LED keeps blinking, then there could be some issues like no IP address, or local proxy server setting required...etc. To set static IP or Proxy, or managed VLAN, you can login to Local Access Page through Managed SSID of the AP.

ECS Switch Installation

ECS Switch Package Contents

Connecting to ECS Switch

A) Connect the supplied power adapter (or power cord) to the switch and plug the other end into an electrical outlet. Verify the power LED indicator is lit on the switch. Wait for the switch to complete boot up. It might take few minutes to complete the process.

B) Connect one end of a category 5/6 Ethernet cable into the gigabit (10/100/1000) Ethernet port on the switch’s front panel and the other end to the Ethernet port on the computer. Verify that the LED on the Ethernet port of the switch is green.

Login to the ECS Switch Local Access Page

The switch's default IP address setting is DHCP client mode, which will get an IP address from the DHCP server. It will automatically change to static IP address assignment if the switch cannot get an IP address from the DHCP server within two minutes of booting up.

If your switch cannot get an IP address from local DHCP server, or you would like to use static IP address assignment, you may follow the below procedures to manage your computer connection to the switch via a static IP address.

IP address configuration on your computer:

A) Once your computer is on, configure the settings of your network adapter. Open Network Connections > Local Area Connection > Internet Protocol Version 4 (TCP/IPv4) > Properties

B) Select Use the following IP address and make the following entries:

• IP Address: 192.168.0.10 (or any address in the 192.168.0.x network)

• Subnet mask: 255.255.255.0

Login to ECS Switch

A) Open a web browser on your computer. In the address bar of the web browser, enter the ECS switch IP address and hit enter.

B) The default username is admin and the password is password. We strongly recommend that you change these as soon as possible. Enter the username and password of the switch and then click Login.

*Your model number may be different in the web browser interface.

C) ECS Switch local access page will appear.

Other Languages:

Before You Begin

To start using the EnGenius Cloud service, you must prepare the following:

• At least one supported EnGenius Cloud wireless access point or switch.

• An existing network with an Internet connection including DHCP and DNS configuration.

Supported Web Browsers

The EnGenius Cloud is primarily accessible with a web browser. Before signing up for the EnGenius Cloud service or logging on to the web interface to manage your network, first verify that you are using a supported browser.

The following table lists the web browsers that EnGenius Cloud supports:

If you use an unsupported web browser, you may experience issues displaying elements on the web interface.

ECW AP's

The first step is to get the serial numbers of the Cloud equipment you want to add to your cloud account. The serial number can be found on the box of the Cloud AP (ECW) or Cloud switch (ECS). An example of each is below:

1. Model number of ECW AP

2. Serial Number of ECW AP (This string of information that is added in the Cloud GUI)

3. Hardware version on ECW AP

The serial number for an ECW AP can also be found on the sticker on the back on the unit (check where you plug in the Ethernet cords into the ECW AP)

Below is an example of the sticker on the back on an ECW220 AP.

As you can see the sticker on the back of the AP has the MAC address of the AP as well. It has the following items:

1.Model of AP

2.Serial number of ECW AP (This string of information that is added in the Cloud GUI)

You can also find the serial number of the ECW AP In the GUI of the ECW AP, when you login into the unit.

Highlighted below is the information needed to add the AP to the Cloud GUI, if the information is obtained via login to the ECW AP locally in the web GUI.

1. Model of the AP

2. Serial Number of ECW AP (This string of information that is added in the Cloud GUI)

3. Firmware version the AP is currently running

ECS Switches

Below is the sticker that is on the box of the ECS switch

1. Model of the ECS switch

2.Serial Number of ECW AP (This string of information that is added in the Gloud GUI)

3. Hardware version of the ECS switch

4.Firmware version that the switch came shipped with

Below is the information you find when you login to the ECS switch locally and go to System > Summary from the left hand column.

1. Model of ECS Switch

2. Serial Number of ECW AP (This string of information that is added in the Gloud GUI)

3.Firmware version the switch is currently running

Before devices can be assigned to the network, they must be registered to an Organization that you preferred in advance.

1. Locate the serial number located on the bottom of the device.

2. Navigate to Organization > Inventory & License and click the Register Device on the top of the table.

3. Enter the serial number that you located in the device and enter them. If you have multiple devices you can enter the SN one per row, so devices could be registered at once. And then click the Register button.

A collection of hierarchy views and networks that are part of a single organizational entity, such as a company or school district. Each organization is the owner of a single license.

Adding an organization

Click Menu > Create Organization button to create organization

Edit Organization

Edit a organization if you need to update any its current settings (for example, if you want to change the Organization name, Country, TimeZone.)

Follow these steps to edit a Organization.

1. Click Menu > Find the Organization you want to edit > Edit

2. Update Network Settings as required

3. Click Apply

Delete Organization

If you no longer need a Organization that you previously created, you can delete it.

Follow these steps to delete a organization

1. Click Menu > Find the Organization you want to edit > Delete

2. Popup is displayed and click Confirm

A hierarchy view is a group of networks and/or nested hierarchy views. It follows a tree-like structure much like folders on your computer's operating system.

Adding a hierarchy view

You can create hierarchy views for a new organization or an existing organization, or even within an existing hierarchy view. Click Menu > Choose organization or hierarchy view > Add hierarchy view

Edit hierarchy views

1. You can edit the name of a hierarchy view name by clicking Menu > Choose hierarchy view > Edit

2. Change the Hierarchy View name and click Apply.

Delete Hierarchy View

You can delete hierarchy views by clicking Menu > Choose hierarchy view and then clicking on the garbage icon.

Move Network under Hierarchy View

After created Networks and associate devices, if the HV is changed, say, the Network originally belongs to North Region, and now become North-East Region, users have to change the HV and would like to move the Network under North-Region to North-East-Region. This allows users to "drag & drop" any Network to new HV under same Organization.

EnGenius Cloud adopts an organization tree structure to let user define the scope of their managed networks. All device managing or monitoring functions can be applied to different scopes as laid out in the user's tree. That gives VAR or MSP users great flexibility in managing their networks.

The current organization tree structure consists of three levels, from largest to smallest:

• Organization - A grouping of one or more hierarchies under the umbrella of a single license.

• Hierarchy View - A cluster of networks, which may be geographically concentrated or spread out.

• Network - A set of network devices united by a single configuration set.

The organization tree definition is shown on the top left corner of the web GUI as follows:

How-to Videos

How to build your company networks in EnGenius Cloud

https://www.youtube.com/watch?v=sN2y44Yzi7s&feature=youtu.be&t=5

This page will show you the VPN status of the Gateway in relation to all other EnGenius Gateways or Non-EnGenius Gateways in your organization with site-to-site VPN enabled. You can access the VPN Status page by navigating to Manage > VPN Status.

If you are in the Organization scope, you could select the gateway to monitor the current VPN status in relation to other EnGenius Peers or NonEnGenius Peers by switching the tab

Under the EnGenius Peers tab, the following information is available

• Gateway: The name of the EnGenius Gateway.

• Network: The Network to which the gateway is assigned.

• WAN IP: The WAN IP of the remote gateway.

• Subnet: The remote subnet network address behind the remote gateway that can be reached through Site to Site VPN.

• Type: The type that is configured on the Configure > Gateway > Site to Site VPN

• Usage: The amount of traffic to and from that EnGenius VPN peer.

• Latency: Round-trip time latency between the EnGenius Gateway and the remote peers.

• Uptime: This shows the time that the VPN tunnel has been active

If You are in the Network scope, it will display the gateway in the network to monitor the current VPN status in relation to other EnGenius Peers or NonEnGenius Peers.

On the non-EnGenius peer's tab, the following information is available

• Gateway: Name of the EnGenius Gateway.

• WAN IP: The WAN IP is configured for the non-EnGenius peer.

• Subnet: The remote subnet network address behind the remote non-EnGenius gateway that can be reached through Site to Site VPN.

VPN Map

Users can drag & drop EnGenius Gateway and Non-EnGenius Gateway in the Organization to Google Maps and have a holistic view of the gateway deployed on google Maps and see the VPN topology. You can access this page Manage > VPN Status > Map

the color will show the latency of the VPN link to let the user has a quick view of the quality of each VPN link.

Once you created Orgs and Networks to define the scope of managed networks, next step is to add the devices to the managed network and manage them. To manage the Access Points in a Network, trigger the toolbar menu at the left-hand side: Manage > Access Points.

Add an AP to Network

Click on Add from Inventory button. You can then pick the devices registered to the Org previously and add them to current Network.

Quickview Panel

Single click on the row of a AP (anywhere but hyperlink). It invokes a Quickview Panel that helps showing important status and key configurations for you. User can quickly finetune settings and do comparisons among different APs without going in and out different pages.

Customize Radio Settings

It's pretty common that for some cases you need to set channel or Tx power for specific APs. This would require the capability to override network's default radio settings.

Follow these steps to customize the radio settings for an AP.

1. Choose an access point from the list to show its expanded settings.

2. In the Radio section, click the checkbox below the lock icon to override default settings.

3.Configure the following settings for both the 2.4GHz and 5GHz radio band:

• Channel

• Tx Power

• Channel Width

4. Click Apply.

Customize SSID settings

Although APs in the same network share the same SSID settings, sometimes you just do not want a specific AP to enable all SSIDs in the network. For example, you don't want the SSID of financial department to be enabled and accessible everywhere. In the Quickview Panel, you can also finetune and override SSID settings.

Follow the steps to override network-wide settings and enable or hide the SSID of a network.

1. In the WLAN section, click on the checkbox near lock icon to override default settings.

2. Configure SSID to be enabled or hidden per your request.

3. Click Apply.

Manipulate APs in a Network

Once you have APs added to the network, you can apply more actions on the APs:

• Move

  Select one or multiple access points and click to move the AP(s) to another hierarchy view/network.

• Remove

  Select one or multiple access points and click to remove from the current org/hierarchy view/network.

A network contains a list of devices and relevant information, such as configuration, SSID, radio settings, and firmware upgrade history. Each network contains a single configuration set for its devices, so if you have multiple configurations for devices, you can create a separate network to handle that.

Adding a network

1. Click Menu > Choose organization or hierarchy > Create network

2. Enter a name for the network, select the country, time zone, and then click Create.

Edit Network

Network name, country, and timezone can be edited as needed. Follow the steps below to edit a network.

Choose network > Edit

Delete Network

If you no longer need a network that you previously created, you can delete it.

Follow these steps to delete a network.

1. Click Menu > Choose network > Delete

2. Popup is displayed. Click Confirm.

This allows you to run the diagnostic tests that can help the Network administrator to troubleshoot.

Under switch detail page > you can easily see the “Diag Tools” icon

Under Manage > Switches > Diag

So the Full-screen tools are displayed, So you can use them.

Activity

Overall port status view - It’s a good way to let users see all ports throughput at a glance

The bar indicates the throughput of the port and the color of the bar indicates the speed of the port.

CRC error

This is an important indication to see if anything is wrong with the transmission including the cable issues. The red square indicates there are CRC errors found. Users can mouse over to the port and see more details of throughput and CRC error count.

Clients list (FDB)

This is the real-time client list of the Switch or the content of the forwarding table. Users can refresh the table by clicking the refresh button

Cable Diag

Cable diag helps to check the Cable status of selected ports. (It can be multiple selections) and will show the possible distance of breaking points.

ARP Table

In order to send packets on LAN, network devices need to know the IP and MAC address of the hosts they intend to communicate with. Address Resolution Protocol provides the mechanism to determine the MAC address associated with an IP address. These IP to MAC bindings are stored in each switch's ARP cache.

Packet Capture

The packet capture utility can be used to observe live network traffic passed by EnGenius Switches. Since captures provide a live snapshot of traffic on the network, they can be immensely helpful in diagnosing and troubleshooting network issues. This article outlines how to remotely take a packet capture in Diag tools.

How to use it

1. Choose ports to capture packets > input Duration in sec > click on “Capture”, then the Switch will collect the packets and download them with the .pcap file

2. Download Wireshark or other packet analysis tools to open up the .pcap file

AirGuard is EnGenius technology to detect the rogue source, evil twins, DoS attacks, and RF jamming. You can access this screen under Manage > AirGuard

Rules

1. Users should enable AirGuard first (by default: off) to activate AP to detect the rogue source

2. If Enabled "Contain all Rogue Devices", all rogue SSID devices will be contained automatically and Zero-Wait DFS will not be functional.

3. Scanning APs list down all APs who can do AirGuard (AirGuard AP), click “Details” will redirect to the AP detail page.

4. Users can set rules to categorize specific SSID or BSSIDs with a partial match or exact match.

Rogue SSID

• All SSID match “Rogue rules”

• All SSID match legitimate SSID but are not recognized by Cloud-managed device (It could be rogue AP, it also could be other vendors' legitimate AP)

• Broadcast MACs are the BSSID (MAC), detected by our AP, broadcasting the rogue SSID. It could be multiple BSSIDs. Click on the line to see detailed information.

• Seen by: the Rogue SSID might be detected by multiple EnGenius AP

• Severity: The rogue reason severity could be high and require the user’s attention. The color bar in front of the SSID indicates the severity: Very high: Red; High: Orange…

• Containment: Contained means the rogue SSID that your EnGenius AP is currently containing. Whenever a client attempts to connect to the rogue SSID, they will be forced off. Uncontained means the Rogue SSID is not currently contained.

• Move to Whitelist: If the user found the SSID should be legitimate, then he can select it and move to whitelist (move to “Other SSIDs”)

• Contain: This is the action that if you determine the Rogue SSIDs are threats to your network, you could click contain so the client will be forced off when the client attempts to connect the Rogue SSIDs.

• Uncontain: This is the action that the Rogue SSIDs were noticed during a scan, but has not been determined to be a threat to your network, so you could click Uncontain.

Evil Twin

• AP impersonation: SSID = legitimate SSID and BSSID = legitimate BSSID, which means someone is using the legitimate AP’s MAC and SSID trying to steal client information

• AP spoofing: BSSID = legitimate BSSID, but not legitimate SSID

• The severity is always “Very High” and requires attention.

Malicious Attack

DoS attack trying to let clients or specific clients not able to connect to the AP

• De-Auth attack: The rogue client sends a high volume of “De-Auth” traffic, so clients are always de-auth.

• Dis-association attack: The rogue client sends a high volume of “Dis-association” traffic, so clients are always disassociated.

• Attacked Party: Either specific client (MAC address) or broadcast (all MAC ff:ff:ff:ff:ff:ff)

RF Jamming

RF Jammer sends RF noise on a certain channel to increase the SNR rate or keep the SSID/channel busy, so the client cannot connect to SSIDs on the channel.

Other SSID

• There are many BYOD devices (employee’s mobile phones) broadcasting SSID for their own use, which is harmless

• Whitelisted SSID

For each Gateway, EnGenius Cloud collects and aggregates lots of data reported by the Gateway periodically. Sophisticated graphs and tables are available on the gateway detail page to ease the monitoring and tracking of a gateway. To get all the details, on the Gateway page, hover your mouse cursor on the row of Gateway you are interested in. A Detail button is shown click on it to get into the Gateway detail page.

WAN

This will display the WAN Info that you configured in the Configure > Gateway > Interface > WAN

WAN Info

• Interface: Display WAN1 or WAN2

• Name: The name of WAN1 or WAN2

• Connection: DHCP, PPPoE, or Static

• Public IP: This is the Internet public IP address of the WAN interface seen by the EnGenius Cloud. If there is an upstream NAT device, then this is the public IP address of the NAT device. If the gateway WAN interface is directly connected to the Internet, then this is the native IP address of the WAN interface.

• WAN IP: The native IP address of the WAN interface. If the WAN interface is directly connected to the Internet, then this IP address is the same as the Public IP. If the WAN interface is connected to an upstream NAT device, then this IP address is usually a private IP address.

• Gateway: the Gateway IP address of the WAN interface which is used as the next-hop gateway for Internet access through this WAN interface.

Latency

This graph shows the Latency between the EnGenius Security Gateway and Google Public DNS in a day/week/month view. Hover and click Day/Week/Month to see the latency graph view by Day/Week/Month.

LAN

The LAN tab displays the following information.

• LAN Interface: the name of the LAN Interface

• Subnet: the subnet IP address of the LAN Interface of the gateway

• Used: the number of leased DHCP IP addresses of the gateway DHCP server for this LAN interface

• Free: the number of remaining leasable DHCP IP addresses of the gateway DHCP server for this LAN interface

DHCP Lease

The DHCP Lease tab shows the current DHCP leasing status of the gateway. The following information is displayed.

• Client: the name of the DHCP client

• MAC: the MAC address of the DHCP client

• IP: the DHCP IP address of the DHCP client

• LAN Interface: the LAN interface that the DHCP client was connected to

• Expires in: the expiration time of the leased DHCP IP address

The following clients will not appear in the DHCP leases table:

• Clients with statically assigned addresses

• Clients with fixed DHCP assignments

• Clients receiving an address from another DHCP server

• Clients that have not successfully received an address from the EnGenius Gateway

• Clients connected over the client VPN

This allows you to view and configure PoE schedules that can be applied to the ports. Below screens display the existing schedules visually. Click Manage > Switch lists > detail > PoE scheduling to access this screen

Edit PoE Scheduling

1. Select the ports to be set the PoE scheduling then click Edit

2. Enable scheduling and then customize the PoE on or Off by dragging the bar. This behavior is the same when you configure the SSID scheduling.

3. If you want to do the PoE reset, you can simply click PoE rest and then drag the icon to the specific time.

4. Click Apply.

Click Manage > Switches to access this screen and double-click the organization/hierarchy view/network on the tree to change the scope.

The Switch List page lists all switches within your organization/hierarchy view/network, and allows you to choose each switch to view the port status, VLAN , STP and PoE.

The following describes the functions in this screen:

Move to: Select one or multiple switches and click to move the switches to another hierarchy view/network.

Remove From Networks: Select one or multiple switches and click to remove the switches from the current organization/hierarchy view/network.

Add From Inventory: Click this button to add switches from your existing inventory.

Detail: Click to display the individual switch details.

Manually Configuring VLANs individually

you can access this page through Configure > Switches > Detail > VLAN

Using the VLAN tab, you can manually configure VLANs on the switch. Click Add to add another VLAN.

enter the VLAN ID and VLAN name of the switch.

Click the edit button to have the Port Assignment.

You can click the Tagged field or Untagged field to assign the tagged / Untagged port.

The (T) indicates the ports that will have Tagged data.

The (U) indicates the ports that will have data Untagged

If you used to input manually. You can click the pencil icon to input the port numbers.

Remember to click Apply to finalize the settings

Configure multiple VLANs at a time using a JSON file

For Apartments or other network environments, a network administrator might need to create VLANs for each unit, so needs to create hundreds of VLANs for the whole network switches. This will help the network admin to configure VLAN at a time instead of creating the VLAN one by one in each switch.

VLAN Export

This will export the current VLAN JSON file of the switch and allows you to edit locally.

VLAN Import

You can manually set up multiple VLANs for a specific switch by importing a JSON file.

Click the example hyperlink to download the JSON file

and then adjust the VLAN settings locally

then click JSON file upload to import your custom JSON file.

So you can import VLAN settings at a time instead use the current Web GUI to edit them one by one. Please notice that It will override your VLAN settings if you ever create the VLAN manually.

After a single configuration, you can go to another Switch VLAN setting page to import the same text file, so to save time to go over the creation.

ECW120

ECW115

ECW160

ECW215

ECW220

ECW220S

ECW230

ECW230S

ECW260

ECW270

ECW336

From the Switches page, you can click Details on the web interface to display detailed information about a switch.

Summary

PoE reset from the Switch Panel : User can mouse-over to the PoE port of the switch port panel and power-cycle the port, so the device attached to the port will be rebooted

Total PoE Usage: This bar graph displays the consumed, remaining, and total wattage utilized by Power over Ethernet.

Total PoE Utilization by Port: Displays the current PoE utilization by each port, in watts.

System Setting

The System Settings section allows you to configure all primary networking options for your switch.

Spanning Tree Protocol

A Spanning Tree Protocol is a Layer 2 protocol that prevents loops in a network with redundant paths created by multiple switches. We recommend using this feature if your environment incorporates multiple switches.

Procedure

1. Enable the STP option

2. Select a Protocol

3. Select a Bridge Priority value

4. Click Apply

LLDP

The Link Layer Discovery Protocol (LLDP) is a Layer 2, vendor-neutral protocol that allows network devices to advertise capabilities, identity, and other information. This data can potentially be queried by SNMP.

Procedure

1. Enable the LLDP option

2. Click Apply

Voice VLAN

The Voice VLAN feature configures switches to automatically allow and prioritize voice traffic over a designated VLAN. This keeps voice traffic separate and prioritized over other traffic types.

Mode: Allows you to define the Voice VLAN mode.

• Auto: Automatically advertises the Voice VLAN to connected devices via the LLDP-MED protocol.

• OUIs: Determines whether a received packet is a voice packet by checking its source MAC address.

Switch Voice VLAN: Allows you to choose what VLAN is used for Voice VLAN. You can set up VLANs in Port Settings.

QoS Priority: Lets you define whether the switch will use the Quality of Service CoS value of the incoming packet, or tag the packet with a CoS value between 1-7.

OUIs: VoIP traffic has a pre-configured Organizationally Unique Identifier (OUI) prefix in the source MAC address. You can manually add a specific manufacturer's MAC address and description to the OUI table. All traffic received on the Voice VLAN ports from the specific IP phone with a listed OUI is forwarded on the voice VLAN.

QoS

Quality of service (QoS) allows operators to prioritize application traffic to ensure that latency-affected data, such as VoIP and video conferencing, is uninterrupted during periods of network congestion. Switches implement this by reading tagged packets and prioritizing them accordingly. Packets are classified using Class of Service (CoS) on the data link layer, and Differentiated Services Code Points (DSCP) on the network layer, mapped to a queue, then sent out accordingly as per QoS.

Trust Mode: Allows you to define whether the switch will use CoS, DSCP, or both trust modes for QoS.

Scheduling Method: Allows you to define what method the switch will use when assessing transmitting incoming packets in queues. Strict priority always prioritizes queues with a higher priority, while Weighted Round Robin (WRR) weights each queue by priority, then applies a round-robin policy when choosing packets for transmission. The queues are weighted as follows:

Queue Mapping: Tagged packets are sent to queues defined in this setting. For each CoS or DSCP value, you can choose the queue to which tagged packets are mapped.

IGMP

IGMP Snooping is used for controlling multicast traffic. It listens to IGMP messages being processed by the switch and prevents these messages from being sent to hosts not part of the respective multicast.

Version: The available IGMP Snooping versions are v2 and v3. You can select either/or in the Version dropdown.

VLANS: You can enable IGMP Snooping for any VLAN by selecting the corresponding checkbox next to the VLAN ID.

Jumbo Frame

Ethernet has used the 1500 byte frame size since its inception. Jumbo frames are network layer PDUs that have a size much larger than the typical 1500 byte Ethernet Maximum Transmission Unit (MTU) size. Jumbo frames extend Ethernet to 9000 bytes, making them large enough to carry an 8 KB application datagram plus packet header overhead. If you intend to leave the local area network at high speeds, the dynamics of TCP will require you to use large frame sizes.

The switch supports a jumbo frame size of up to 9216 bytes. Jumbo frames need to be configured to work on the ingress and egress port of each device along the end-to-end transmission path. Furthermore, all devices in the network must also be consistent on the maximum jumbo frame size, so it is important to do a thorough investigation of all your devices in the communication paths to validate their settings.

Jumbo Frame : Enter the size of a jumbo frame. The range is from 1522 to 9216 bytes.

Port Settings

Selecting one or more ports and clicking Configure will display the following settings:

Enabled: Allows you to enable or disable the connection for this port.

Label: Allows you to add a descriptor for this port.

Speed/Duplex: Allows you to define the following speed/duplex communication settings for this port:

• Auto: Speed/Duplex will auto-negotiate based on the connected node.

• 1Gbps / Full Duplex

• 100 Mbps / Full Duplex

• 100 Mbps / Half Duplex

• 10 Mbps / Full Duplex

• 10 Mbps / Half Duplex

Power over Ethernet (PoE): Allows you to power a connected device through an Ethernet cable using your switch.

VLANs: Allows you to group devices to create a partitioned network on the same LAN.

Forward Ports: By configuring the forward ports, ports can be separated into different groups where traffic between different group are blocked.

Rate Limit: Allows you to limit the amount of incoming and outgoing traffic in Mbps.

Flow Control: Enabling this will have the switch regulate traffic during times of congestion.

QoS: If QoS is enabled in Switch Settings, you can configure additional settings per port.

• CoS Value: All incoming packets that lack a CoS value will use the one set in this dropdown.

• Trust CoS: If checked, the switch will queue packets tagged with CoS into their designated queues. If unchecked, all packets will leave the same queue.

VLAN Trunking: This allows the specific ports to receive/forward VLAN without adding this port to the member port of a specific VLAN. please notice that VLAN trunking will override the current VLAN port member setting except management VLAN.

Override System setting on the Switch Network-wide setting

System setting is followed by Switch setting from the Configure > Switch settings as default settings. If you want individual AP System settings to be different from the Switch Network- wide setting , you can click below part in the screen to override the setting .

Port Mirroring allows you to copy packets on one or more ports to a mirroring destination port. You can attach a monitoring device to the mirroring destination port to view details about the packets passing through the copied ports. This is useful for network monitoring and troubleshooting purposes. The feature is available is at Manage > Switch < Details > Mirror

The following describe the labels on this screen :

Session id : A number identifying the mirror session. Switch supports up to 3 mirror sessions.

Session State : Select whether to enable or disable port mirroring.

Destination Port : The port which all mirrored data is sent to .

Ingress : indicates that only data being received will be mirrored.

Egress : indicates that only data being sent will be mirrored

How to configure

1. Click the edit icon towards the right .

2. Enable the Session state.

3. Select the Destination port

4. Select the Ingress and Egress port

5. Click Apply

Port state

There are four types of port that you configured .

If Outlet AutoReboot is Enabled, PDU will perform a power cycle for outlets that are ON when communication with the assigned Website/IP Address is lost.

You can access this page from Manage > PDUs > Detail > AutoReboot

Configuring the Outlet Reboot

To configure the outlet reboot, complete the following steps:

1. Select the outlet from the list and click Edit.

1. Enable the AutoReboot function.

2. Specify the condition that prompts an auto reboot and enter the host details.

1. Click OK and then click Apply.

Outlet Timeout settings

This allows you to configure the Autoreboot timeout settings.

• AutoReboot Ping interval: the time period that will ping to the connected devices.

• AutoReboot Delay time: Sets the amount of time before AutoReboot resumes pinging once an auto reboot has been performed.

• AutoReboot Attempts: Amount of Auto Reboots to attempt when communication with a Website/IP Address is lost.

Link aggregation groups multiple ports together in parallel to act as a single logical link. Aggregation-enabled devices treat all physical links (ports) in an aggregation group entirely as a single logical link (port). Member ports in an aggregation group share egress/ingress traffic load, delivering a bandwidth that is multiple of a single physical link. The feature is available is at Manage > Switch < Details > Link Aggregation

How to Configure

To Configure trunk , you must select aggregation type . Select from the following options:

• LACP: LACP is a dynamic protocol which helps to automate the configuration and maintenance of LAG’s. The main purpose of LACP is to automatically configure individual links to an aggregate bundle, while adding new links and helping to recover from link failures if the need arises. LACP can monitor to verify if all the links are connected to the authorized group. LACP is a standard in computer networking, hence LACP should be enabled on the Switch's trunk ports initially in order for both the participating Switches/devices that support the standard to use it.

• Static: Static configuration is used when connecting to a switch that doesn't support LACP.

• Disable : Disable the trunk that you configured previously.

Then select the Member Ports to add into the trunk group. There are two ways to select the ports

1. Click on the port picker to select multiple ports.

2. Click Pencil icon to input port numbers

After you complete the trunk settings , remember to click Apply to take effect .

PDLG is a function that will automatically reboot PD devices when PoE switch found it was not responding. Which minimizes the downtime of network services and reduces admin effort via automatic processes.

• In PDLG force ping mode, user have to set PD device IP manually. By keep pinging PDs, switch knows if PD is still alive or has to be rebooted.

• PDLG also support auto mode which allows switch collecting PD information/status through LLDP preventing any PD IP changes under DHCP environment.

• By fine tuning the reboot profiles, PDLG can correctly detects/reboot various PDs since every PD devices may have different response or bootup time.

ACLG is one of the option in PDLG auto mode. By enable ACLG, switch also considers Onvif discovery result to verify if the connected PD is surveillance device or not. Once switch make sure it is a surveillance device, it applies a ACLG reboot profile to corresponding port automatically.

• Specified IP: Setting specified IP on a specific port.

• Ping Interval: Setting ping IP interval on a specific port.

• Ping Max Count: Setting ping max count on a specific port.

• Power Recovery Interval: The waiting time between power off and power on a specific port.

• PD BootUp Time: Setting Powered Device boot-up time on a specific port.

• Reboot Max retry count : Setting the max number of reboot

• LLDP/ACLG Expiry pending time: Settings the corresponding LLDP expiry pending time.

The default value of PDLG ＆ ACLG is from the network wide profile settings

You can click lock icon to override the settings

This allows you to view and configure outlet schedules that can be applied to the outlets. Below screens display the existing schedules visually. Click Manage > PDUs > detail > Schedule to access this screen

Edit Outlet Scheduling

1. Select the outlets to be set for the outlet scheduling then click Edit

2. Enable scheduling and customize the outlet on or Off by dragging the bar. This behavior is the same when you configure the SSID/ PoE scheduling.

• Available: the outlet will be powered on according to the scheduled criteria.

• Unavailable: the outlet will be powered off according to the scheduled criteria.

3. If you want to do the outlet reset, click outlet reset and then drag the icon to the specific time.

• Outlet reset: Specify when to temporarily disable and enable the outlet when the outlet's availability is set to Available.

4. Click Apply.

Outlet Schedule can be configured up to three timeslots in a day

Provide a more flexible schedule configuration, allowing users to adjust the specific days of the week for each outlet according to environmental needs to set up to three available time slots.

How to do it:

1. Navigate to MANAGE > PDUs > Schedule to select the specific outlet and then click the Edit Button.

2. Use the parameters of the "Time Slider" to adjust the availability of time slots for each day.

Available firmware: PDU firmware v1.0.5 or later version.

When the actual Amp/Voltage exceeds the configured Voltage/Amp safe range, Cloud will log the events.

You can access this page from Manage > PDUs > Detail > Alerts

Overall Voltage Safe Range

You can drag the bar to adjust the safe range and enable to logging the event that exceeds the configured voltage safe range.

Outlet Amp Safe Range

You can drag the bar to adjust the amp safe range and enable to logging the event that exceeds the configured Amp safe range.

This screen allows you to locate a device on the world map to show the relationship between the space and EnGenius Devices. Maps provide a visualization for buildings and access points.

Create Buildings

A building means a group of floor plans. You can create a new building with the + button.

After you create a building, you can drag it to the map. Single-click on the building icon and a hyperlink will appear to allow you to edit floor plans.

How to Place Access Points or Buildings on the Map

1. Click access point list or buildings list.

2. Enter the street address in the address field.

3. Drag the access point/building onto the map.

Navigation

There are a number of ways to navigate through the map display.

Single Click: If the user single-clicks on the focus icon on the access point or building lists, it will auto-locate the same item in the map.

Double Click: If the user double-clicks on the building icon in the access point list, the UI will auto-navigate to the floor plans of that building.

The Client Timeline is a great feature that aggregates and analyzes activities of a specific wireless client to provide an intuitive and historical view. With Client Timeline, user can easily know how clients associate, authenticate, and roam among Access Points. It is extremely useful when you need to debug or trace your wireless network. The feature is available at Manage > Client > Client name.

Client States

The EnGenius Cloud AI system categorizes client activities into five different states:

Client was connecting to an AP. Client was roaming and connecting to another AP. Client changed to associate with different radio or SSID of the same AP. Client failed to authenticate with an SSID. Client was denied because of it is in block list.

The states are displayed at the left hand side of timeline. User can easily see how a client transited its states among APs.

Radio Color Conventions

The drawing and content of client timeline follows the color conventions as below:

• Green: represent a 5G session.

• Blue: represent a 2.4G session.

Transition Details

The communication between wireless client and AP could be very complicated. Different clients with different wifi chips and wireless drivers can behave very differently while communicating with the same AP. The intelligent engine behind Client Timeline is capable of analyzing communication packets effectively and performs clean and human readable transition details for the user.

User can click on the event summary inside a connection session to expand the sequence of transition details:

Table below displays client leave patterns when client leaves each connection session.

Wireless Clients

EnGenius Cloud provides management views that collect information about connected clients in your organization/hierarchy view/network.

Click Manage -> Clients to access this screen and double-click the organization/hierarchy view/network on the tree to change the scope.

Filtering the Clients List

The list of clients can be customized based on time intervals, and the chart can be customized based on time intervals and SSIDs. To change these parameters, use the appropriate dropdown menu at the top of the screen.

Searching for Clients

You can search for a client in the current client list by using the search. You can search by any parameter included in the search options, and it will attempt to match your query across all fields. You can also specify multiple parameters by clicking on the icon in the search box, as seen below:

Block Clients

This allows you to block clients on the current SSID that clients connected.

Once you want to unblock clients, please go to Configure > SSID > Access control to delete the Mac Address from the Block list.

VIP Clients

This allows you to make clients VIP on the current SSID or on Network-wide that clients are connected.

Once you want to delete clients from the VIP list, please go to Configure > Access control to delete the Mac Address from the VIP list.

Kick Clients

If you don't want to block clients permanently, you could just kick them so that they can connect again if they want to.

Wired Client

This will display the clients that are directly connected to the downlink port on switches.

Gateway Clients

This will display clients that are assigned by the Gateway DHCP server.

You can also see this information regarding the client:

• MAC Address - The MAC address of the client device in the packets sent from the device.

• IP - Assigned IP address of the client device.

• Hostname - Host Name of the client device.

• OS - Operating System that the device is Running.

VPN Clients

After configuring the client VPN and users are starting to connect, it may be useful to see how many and which client devices are connected to your network. To see connected client VPN devices, navigate to Manage > Clients > VPN Client

You can also see this information regarding the client:

• Name: the name of the VPN client.

• VPN IP: the IP of the VPN client.

• Remote IP: the external IP of the VPN client.

The LCD panel on the front of the PDU allows you to quickly access information about the PDU and its outlets. When you power on the PDU for the first time, the EnGenius logo will appear, followed by a QR code. You can scan the QR code to access the PDU quick start guide.

To access the Home page, long press the bottom of the control buttons beside the LCD panel. The Home page shows the current PDU usage, including the usage percentage, wattage, electric current, and voltage. The usage percentage is divided into four levels to indicate the overall power consumption status:

• Green: Low usage.

• Orange: Moderate high usage.

• Red: High usage.

• Dark red: Critical usage.

You can check the usage of each outlet by pressing the upper control button. Pressing the upper control button again will show the usage of the next outlet. The following screenshot shows the Outlet 6 details of an EnGenius switch (the model name is ECS1008P) that is plugged into the PDU.

The next time you power on the LCD panel, the Home page will be displayed automatically.

Using the LCD Panel

See below for how to use the LCD panel.

Understanding the Different Icons

See below for the different icon definitions.

Navigating the Menu

To access the Menu, complete the following steps:

1. Go to the Home page.

2. Press the lower control button.

To navigate through the options, use the upper control button, which functions as the Next button. To view the details of a selected topic, use the lower control button as the Enter button. In some cases, you may need to drill down further to view more specific details.

Full Menu List

The following shows the available options displayed on the Menu.

Outlets

Displays the following information when an Outlet is selected.

Press Menu > Outlets > (Select an outlet).

• Peak Data: Recorded the highest current and power usage over a specific time interval.

• Data Interval: Frequency at which the PDU collects and reports power/current usage information. This information is used to create the line charts in Peak Data.

• Enable: Enables the outlet, so outlet is able to provide power to the connected device.

• Disable: Disables the outlet, so the outlet will be powered off.

• Reset: This will temporarily disable and enable the outlets.

Schedule

Displays the power on / power off/ reset time on the schedule for each outlet.

Press Menu > Schedule

Alert

Displays the alert message for each outlet.

Press Menu > Alert

Information

Displays the PDU details, which include the IP address, MAC address, software version, and time zone.

Press Menu > Information

Display Settings

Displays the following configurable display settings:

Press Menu > Display Settings

• Orientation: Configures the content on the screen to be presented in a horizontal or vertical orientation.

• Theme: Choose between a dark or light theme for the content display.

• Screen saver: the idle time that the LCD will turn off.

QR Code

Displays the QR code to view the PDU quick start guide or product web page.

Press Menu > QR Code

Reboot

Reboots the PDU. The outlets still provide power during a PDU reboot.

Press Menu > Reboot

Factory Reset

The PDU will be restored to its default settings, and all the data will be deleted. The power supply will be temporarily interrupted until the reset process is completed.

Press Menu > Factory Reset

This allows you to run the diagnostic tests that can help the Network administrator to troubleshoot.

Under the PDU detail page > you can easily see the “Diag Tools” icon

or Under Manage > PDUs > Diag

Click it and then the Full-screen tools are displayed, So you can use them.

• Diag Tools are all “real-time”

• PDU diagnostic tools include (1) Activity: CPU/Memory/Power/Current (2) Ping (3) Traceroute

• Ping: We put 3 default servers for users to check the latency change. User can also define their own server for the ping test.

• Traceroute: By default, we set the destination site to Google for the traceroute, and max hop is set to 8, which can be changed by the user. Traceroute allows users to know “the path” from the PDU to the destination and will list every router/gateway (hop) and its latency, so if the destination is unreachable, then there must be some setting issue on the router/gateway; and from the latency of each hop, the user will know the “slow uplink” is caused by which router/gateway. When the latency is over 10ms, the color will change to yellow, and if > 40ms, the color will change to red. These color variations help you quickly identify potential performance issues in the network path. To conduct a trace, click the Trace icon.

There’s a lot that EnGenius Cloud can do to customize a network to meet your specific needs. We’ll walk you through the most common settings here.

For network security, the hotels often set up the room network as a Guest Network with L2 isolation enabled to prevent guests from accessing each other's devices. Under the Guest Network, the guests will be blocked from casting multimedia of mobile devices onto the room TV, which causes inconvenience and a poor stay experience for the guests. The newly released EnGenius SmartCasting feature provides smooth, fast setup and streaming on Guest Networks for media sticks, game consoles, and other devices for an exceptional, personalized entertainment experience. This Intelligent feature of EnGenius Cloud is different from the simple technology of simply casting to a Chromecast and AppleTV.

How SmartCasting Works

1. Create the SmartCasting SSID in EnGenius Cloud, and the SmartCasting SSID will have all casting devices under this SSID and allow them to cast to the device.

2. The SSID of SmartCasting can be accessed with a predefined URL, and this URL will be available for guests via a QR code.

3. By scanning the QR code, the hotel guests will be able to quickly cast the media on mobile devices to the room TV screen.

Access and Enable SmartCasting

1. Go to CONFIGURE>SSID.

2. Create a new SSID for casting devices > choose the SSID type to “SmartCast” > Add casting devices

3. Connect all casting devices to the SSID. 4. Auto or manually add casting devices.

• Auto： Connect your casting devices to the SSID first > The Auto mode will scan the casting devices connecting to the SSID.

• Manual： Manually add the casting devices by their MAC address.

1. Download the “QR code” of each casting device and insert it into the backdrop of the casting device for guests to scan the code showing on the TV or print the QR code out and place it in each room.

Display for Smart Casting on SSID lists

The TV icon will display near the SSID name, which means this SSID has enabled SmartCasting.

NAT Mode

In NAT mode, the EnGenius APs run as DHCP servers to assign IP addresses to wireless clients out of a private 172.x.x.x IP address pool behind a NAT.

NAT mode should be enabled when any of the following is true:

• Wireless clients associated to the SSID only require Internet access, not access to local wired or wireless resources.

• There is no DHCP server on the LAN that can assign IP addresses to the wireless clients.

• There is a DHCP server on the LAN, but it does not have enough IP addresses to assign to wireless clients

The implications of enabling NAT mode are as follows:

1. No NAT client can be talked to the other NAT client, neither same SSID nor different SSID (client isolation enabled and block internal routing)

2. Change the IP range of CP DNS to be same as AP DNS (172.16-23.0.0/16)

Use Cases

NAT mode works well for providing a wireless guest network since it puts clients on a private wireless network with automatic addressing.

Diagram

When an SSID is configured in NAT Mode, wireless clients will point to the access point as their DNS server. The AP then acts as a DNS proxy and will forward clients' DNS queries to its configured DNS server.

Configuring Custom DNS for an SSID in NAT Mode

This allows you to set custom DNS servers for a NAT SSID, instead of using the AP's DNS server. This is typically used to forward NAT SSID clients to a DNS server with custom content filtering.

Configuration

1. Navigate to Configure > SSID, then choose one SSID to customize the DNS settings.

2. Locate the Client IP mode and choose NAT mode then click Custom DNS.

3. Enter the preferred Custom DNS IP addresses.

4. Click Apply.

Bridge Mode

In bridge mode, the APs act as bridges, allowing wireless clients to obtain their IP addresses from an upstream DHCP server.

Bridge mode should be enabled when the following is true:

• Wired and wireless clients in the network need to reach each other (e.g., a wireless laptop needs to discover the IP address of a network printer, or wired desktop needs to connect to a wireless surveillance camera).

The implications of enabling Bridge mode are as follows:

• Wired and wireless clients have IP addresses in the same subnet

User Cases

Bridge mode works well in most circumstances, particularly for Roaming. and is the simplest option to put wireless clients on the LAN.

Configuration

1. Navigate to Configure > SSID , then choose one SSID.

2. Locate the Client IP mode and choose Bridge mode then click Apply.

EoGRE

the EoGRE (Ethernet over GRE, or Layer 2 GRE tunnel ) is to build a GRE tunnel between AP and the remote site, so all traffic of the “EoGRE-enabled” SSID will go through the encrypted tunnel to the remote service center

EoGRE tunnel

When SSID’s EoGRE is enabled, all traffic of connecting clients will be tunneled by EoGRE to forward to TGW (Tunnel Gateway)

The connected client then sends a DHCP request to TGW to get an IP address

Option 82 can be enabled to provide more information for the DHCP server to assign IP accordingly.

DHCP Option 82

DHCP option 82 (also known as the DHCP relay agent information option) is used to prevent DHCP client requests from untrusted sources. The DHCP relay agent will insert more information of “circuit ID” to identify the request is from, say, which AP BSSID (radio mac), which SSID name, and which VLAN ID…, so the DHCP server can identify if the request is from an authorized source, and bases on the information to assign IP.

Circuit ID usually includes which ESSID (SSID name) and VLAN ID the client is connecting to. Remote ID usually includes which AP (AP MAC and BSSID - Radio MAC) is relaying the DHCP requests.

Users can define the fields to add to the Circuit ID and Remote ID. EnGenius Option 82 provides options as below:

• AP Ethernet MAC

• AP Radio MAC

• SSID Name

• SSID Type

• VLAN ID

Configuration

1. Navigate to Configure > SSID , then choose one SSID.

2. Locate the Client IP mode and choose Tunnel (EoGRE).

3. Choose the VLAN (the default value of “VLAN” is SSID default VLAN. If the value is changed, then it will override the SSID default VLAN ).

4. Input the Tunnel Gateway IP ( the IP of the remote site the GRE tunnel will be connecting to ).

5. Decide to enable the DHCP option-82, if yes, Input Delimiter ( how the field is separated in the option 82 frames) and select the Circuit ID and Remote ID and then click Apply.

Security Type

Click Configure > SSID > Click one of SSID > Wireless to access this screen.

​ The following describes the authentication types on this screen:

• Open: Allows any client to associate with this network without any data encryption or authentication.

• WPA2 PSK: Enter a pre-shared key of 8-64 case-sensitive characters to enable WPA2-PSK data encryption.

• WPA2 Enterprise: Select Custom Radius to use an external Radius server or select the EnGenius Cloud Radius to use the EnGenius Cloud for 802.1X authentication.

• OWE: When using hotspots in public, users are given better protection through the Wi-Fi Enhanced Open that provides unauthenticated encryption.

• WPA3 Personal (SAE): This type features easier password selection for users to easily remember. It also feats a higher level of security wherein data stored and data traffic in the network will not be compromised even if the password was hacked and data was already transmitted. The upgrade also enabled the Simultaneous Authentication of Equals (SAE) which replaced the Pre-shared Keys (PSK) in WPA2-Personal.

• WPA3/WPA2 Personal mixed: WPA2/WPA3 mixed mode allows for the coexistence of WPA2 and WPA3 clients on a common SSID. The passphrase for both WPA2 and WPA3 clients remains the same, the AP just advertises the different encryption cyphers available to be selected for use by the client. Clients choose which cypher to use for the wireless connection.

• WPA3 Enterprise: This type was mainly built for tighter and consistent application of security protocols across networks of governments, establishments, enterprises, and financial institutions. Offering optional 192-bit minimum security, the WPA3 will make cryptographic tools better. Hence, better protection for sensitive data.

WiFi Access QR code

This QR code allows you to use your mobile device to connect to the specific SSID.

802.11r

802.11r is a standards-based fast roaming technology that is leveraged when using a secure SSID (WPA2-PSK & WPA2-Enterprise). This option improves client device roaming by reducing the handoff delay in situations where client devices roam from one access point to another. 802.11r is disabled by default on EnGenius Cloud.

This feature can be enabled from the Configure > Access Point > SSID page under Network Scope.

If this option cannot be enabled, please go to Wireless > Security Type to select WPA2 PSK/ WPA2 Enterprise /WPA3 Personal (SAE) /WPA3-Personal/WPA2-PSK mixed in advance.

802.11w

802.11w is enabled when Security Type is not Open. 802.11w enables Protected Management Frames (PMF) for management frames such as authentication, de-authentication, association, disassociation, beacon, and probe traffic. This enables APs to help prevent rogue devices from spoofing management frames from APs. Enable 802.11w will allow APs to begin utilizing Protected Management Frames for any clients that support 802.11w.

VLAN pooling is a feature of EnGenius Cloud that allows you to split a large network into smaller virtual networks (VLANs) to reduce traffic and improve performance. To enable VLAN pooling, you need to select Dynamic Client VLAN Pooling in the WLAN settings and enter the VLAN IDs that you want to add to the pool.

Each client connected to the WLAN will be assigned a random VLAN ID based on MAC hashing algorithm. This helps to isolate broadcast packets and balance the load across different VLANs.

L2 isolation

L2 isolation is a feature to prevent wireless client from communicating with any other devices in the network except gateway. With this feature enabled, not only clients associating with the same SSID cannot communicate with each other (this is so called client isolation conventionally) but also clients cannot access other devices in the same LAN. Another exception is that wired devices added to VIP list are still accessible.

Example Use Cases

• Guest SSID to isolate clients and also stop them accessing corporation LAN resources

• Free WiFi service in which administrator want to keep the authentication simple, e.g., WPA2_PSK, such that customer can access the SSID via QR-code scanning.

Band Steering

Dual band operation with Band Steering detects clients capable of dual band operation and steers them to another frequency which leaves the more crowded band available for communication. This helps improve the end-user experience by reducing channel utilization, especially in high-density environments. Band Steering is configured on a per-SSID basis.

RSSI Threshold

This value defines the minimum RSSI required for dual-band wireless clients to associate to 5G band. If the client's RSSI drops below this threshold, it is only allowed to connect to 2.4G band. The recommended value is -60~-80.

BCMC Suppression

BCMC suppression is a feature to drop all the broadcast and multicast frames on a VLAN except for ARP, DHCP, IPv6 router advertisement, and IPv6 neighbor solicitation.

Broadcast-Multicast traffic from APs, remote APs, or distributions terminating on the same VLAN floods all VLAN member ports. This causes critical bandwidth wastage, especially when the APs are connected to an L3 cloud where the available bandwidth is limited or expensive. Suppressing the VLAN broadcast-multicast traffic to prevent flooding can result in loss of client connectivity.

To effectively prevent flooding of broadcast-multicast traffic on all VLAN member ports, use BCMC Suppression to ensure controlled flooding of broadcast-multicast traffic without compromising the client connectivity. This option is for the controlled flooding of broadcast-multicast traffic and is enabled by default.

Example Use Cases

• Enterprise network with over 1000 active wired or wireless clients in different VLANs.

• Campus network with over 1000 active wired or wireless clients in different VLANs.

EnGenius Cloud AP can leverage Microsoft Azure AD to provide a highly secure authentication process for WPA2/WPA3-Enterprise or Captive Portal. The benefit of using Azure AD is that users may integrate WPA2/WPA3-Enterprise or Captive Portal with Azure AD to identify the specified domain/credentials quickly and account Emails for authentication management.

There are two ways to enable Azure AD to authenticate wireless users with EnGenius Cloud.

• Enable Security Type WPA2/WPA3-Enterprise with Azure AD.

• Enable Captive Portal for user authentication with Azure AD.

WPA2/WPA3-Enterprise with Azure AD

To get started:

• Go to Configure > SSID and select a specific SSID name from the list

• From the Wireless tab, select WPA2 /3 Enterprise for Security Type

• Select Azure AD for user authentication

• Enter the configuration (Host, Port, Account, and Password) for the Azure AD.

Host: IP address or domain name of your Azure AD

Port: Azure AD listening port

Username: Azure admin account (admin@example.com )

Password: Azure admin password

Base DN: dc=example,dc=com (Corresponding to the domain service, such as example.com)

• Click the Apply button to save SSID configurations.

Captive Portal Authentication with Azure AD

To get started:

• Go to Configure > SSID and select a specific SSID name from the list.

• Enable Captive Portal from the Captive Portal tab.

• Select Azure AD for Authentication Type

• Enter the configuration (Host, Port, Account, and Password) for the Azure AD.

Host: IP address or domain name of your Azure AD

Port: Azure AD listening port

Username: Azure admin account (admin@example.com )

Password: Azure admin password

Base DN: dc=example,dc=com (Corresponding to the domain service, such as example.com)

• Click the Apply button to save SSID configurations.

Note: Authentication with Active Directory is a feature in Pro Plan, and it requires a PRO license to enable it.

Captive Portal supports the way to authenticate with an externally hosted LDAP server. The option is available at Configure > SSID > Captive Portal > my LDAP server

Follow the steps below to configure the LDAP service:

1. Click Add a server to add a new LDAP server.

2. Enter the IP address or domain name of your LDAP server in the Host field and the LDAP listening port in the Port field.

3. For LDAP admin, enter the distinguished name of the administrative account to bind your LDAP server, for example, cn=admin,dc=example,dc=com, and the password.

4. Click OK and then click Apply button.

Base DN and Login Attribute

Base DN: When you configure the LDAP server, you can set a Base DN. For example, If your domain name is example.com, you can use the Base DN dc=example,dc=com.

Login Attribute:

1. UID: (default ) use unique ID as the login attribute for user authentication

2. Email: use email format

3. Other text: Use user-defined string

Bandwidth Limit

Bandwidth Limitation ensures that users do not consume more bandwidth than they should. We integrated bandwidth Limitation that enforces upload and download limits. Bandwidth Limitation can be applied per SSID or per user or both. When both SSID and Per Client bandwidth limit are set, that means when the total sum of client bandwidth is less than SSID bandwidth limit, per client can have a maximum of “per client bandwidth limit”. If the total sum is over the SSID limit, then all users will share the upper limit of SSID bandwidth.

Use this screen to configure maximum bandwidth.

Click Configure > SSID > Bandwidth Limit to access this screen.

Download Limit

Set the maximum download stream limit for traffic from the SSID or Per user .

Upload Limit

Set the maximum upload stream limit for traffic from the SSID or Per user .

A captive portal can intercept network traffic until a user authenticates his/her connection, usually through a specifically designated login page.

Click Configure > SSID > Captive Portal to access this screen.

Authentication Type

• Click-through: Users must view and acknowledge your splash page before being allowed on the network.

• EnGenius Authentication: Users must enter a username and password before being allowed on the network. You could edit user settings through Configure > Cloud RADIUS User.

• Custom RADIUS: Enter the host (IP address of your RADIUS server, reachable from the access points), port (UDP port the RADIUS server listens on for access requests, 1812 by default), and secret (RADIUS client shared secret). Optionally, the Accounting Server can be enabled on an SSID that's using WPA2-Enterprise with RADIUS authentication.

• Voucher Service: Edit the access plan for guests for the front desk manager.

• Google LDAP: https://app.gitbook.com/o/-LgVsbFz9VHz6Tj66C_6/s/-Lo1AtG4HHv3uJq1FqqB/authentication-with-google-secure-ldap-server

Redirect URL

Configure the URL to which users will be redirected after successful login.

Redirect to the original URL: Select this option to cache the initial website from the client during the authentication process and then forward it to the originally targeted web server after the user successfully authenticates.

Redirect users to a new URL: Select this option to redirect users to a pre-designated URL after the user successfully authenticates.

Advanced Setting

Session Timeout: Specify a time limit after which users will be disconnected and required to log in again.

Idle Timeout: Specify a time limit for an idle client after which users will be disconnected and required to log in again.

Walled Garden: This option allows users to define network destinations that users can access before authenticating. For example, your company's website.

HTTPS Login: This option allows users to log in through HTTPS. When you enable it, your password is encrypted, so others could not retrieve your information.

Captive Portal supports the way to authenticate via an externally hosted AD server. The option is available at Configure > SSID > Captive Portal > Active Directory.

Follow the steps below to configure your AD service.

1. Click Add a server to add a new AD server in the list.

2. Enter the IP address or domain name of your AD server in the Host field and the AD server listening port in the Port field.

3. For AD admin, enter the AD format: admin@example.com, and the password.

4. Click OK and then click Apply button.

This page allows you to block clients in mac based on current SSID.

The following describes the functions on this screen:

• Add : The entry for you to add the Mac address to be blocked.

• Reset : Clean all the Block list .

• Delete : Delete the list that you selected .

After you add the block list , remember to click Apply to take effect .

This guide is intended to help you set up your splash page. With a splash page, you can channel network users to see a custom page before they can access the Internet.

Before you start configuring a splash page, please make sure the captive portal is enabled in advance.

External Splash Page URL: The external splash page enables the administrator to host their own splash page web server, rather than having it hosted by EnGenius Cloud.

Local Splash page : Local Splash page provides the HTML for a splash page that will be hosted internally on the Access Point . For example , allows you to customize your splash page.

After you complete the splash page, please remember to click Apply.

Using the WYSIWYG editor

You can choose different template from the drop-down menu at the top of the editor.

Once you select your starting template, you can customize it with your message, colors, fonts, and images. EnGenius uses a WYSIWYG (what-you-see-is-what-you-get) editor that also supports HTML editing.

In addition to the standard editing tools along the top toolbar , you can click HTML icon to start editing .

Choosing a starting template

Choose a template from the drop-down menu at the top of the editor. You can customize the content and presentation of these templates to suit your needs . Any edits you make will be a copy of the template, you can go back to the default at any time.

Adding and modifying images

Each splash page template comes with a library of stock images. You can also use the Insert Image tool to add your images and logos.

1. Click the Insert Image button, then navigate to a file, or drag and drop it into the upload images.

2.Double-Click on the image or click insert icon to add the image.

This allows you to clone SSID configuration which you created previously. So you can create Multiple SSID with same configuration easily.

Follow steps to clone SSID

1. Click Clone From

2. Select SSID to be cloned => Click apply in popup

3. Click Apply on tab bar to take effect

This guide is intended to help you set up your network to generate and accept vouchers. With vouchers, you control access on a per-user basis by generating guest passes you can provide to users.

Vouchers can be set to specific time increments and are ideal for hotels, coffee shops, apartments, etc. where you want to limit network access to users for a specific period of time.

Enable Voucher Service

Enable the voucher service by clicking Configure > SSID > Captive portal > Voucher Service.

Remember to click on the Apply button at the top-right corner to confirm your change on SSID settings.

Management URL and Access Plan

Management URL

For each enabled voucher service, a dedicated Management URL is created. Any team members who have permissions of Front-desk Manager or Administrator can log in that specific URL and manage Voucher Users there.

Access Plan

In addition, you can create different Plans for voucher user to identify how long a voucher user can access the network (Access Time) and how many simultaneous login are allowed for that user (Simultaneous Login).

Plan Start Time

The plan start time is an option that defines the plan of voucher service is activated when an account is created or after the account's first login.

Managing Voucher Users

Generating Guest Pass

The first page after you login the Management URL of Voucher Service allows you to generate guest account/password with different manners:

A network Administrator or Front-desk Manager can firstly select a access plan and then select to generate account/password of voucher user automatically or manually. Auto Generation allows you to generate Guest pass in batch , you can fill in the number of the Guest Pass you want to create.

Managing Voucher User

Click on the User Management Button in the toolbar.

A Guest Management Page is performed to list all generated voucher user. You can edit the properties of a voucher user by clicking the user_id of that user or pick the users in that list to delete.

Print the Voucher User Info

In the Guest Management Page, you can also select the users and click on the print button to print the voucher info for end-user. This feature allows you to print voucher users in batch.

Hotspot 2.0, also known as Passpoint, is a service provider feature that assists with carrier offloading. Hotspot 2.0 SSIDs include additional 802.11u information that supported client devices can use to determine if they are able to join the network automatically.

Operation Name : Input the displayed Hotspot 2.0 network name

Venue Name / Type : Input the Venue Name .

Venue Type : Specify the venue groups to be advertised in the IEs from APs associated with this hotspot profile.

Network Type : Access the network type in beacon.

Domain List : This information element specifies the APs domain name.

Roaming Consortium List : This information element contains information identifying the network and service provider, whose security credentials can be used to authenticate with the AP transmitting this element. Input the Roaming Consortium Organization Identifier

3GPP Cellular Network Info: This information element defines information for a 3GPP Cellular Network for hotspots that have roaming relationships with cellular operators. Input the mobile country code and mobile network code.

NAI Realm : This information element identifies and describes a NAI realm accessible using the AP and the method that this NAI realm uses for authentication. Input the Network Access Identifier Realm Names.

AVExpress offers an end-to-end Quality of Service (QoS) solution specifically designed for crucial audio/video (AV) applications, including video conferencing, multi-media streaming, and gaming. It enables users to prioritize traffic based on its importance, ensuring that critical applications receive the necessary bandwidth and low latency for uninterrupted operation.

EnGenius AP will mark DSCP to those traffic to make sure it also gets the same level of priority through EnGenius Switches to reach end-to-end priority

you can access this page through Configure > SSID > Application Control

Application Aware: This allows users to see the application analysis on the client page . Disabling application awareness may improve WiFi performance.

AVXpress: Voice-related traffic will be prioritized as the highest level (Express), other traffic will be under General as normal applications, just like AVXpress is disabled. Fast is in the midst between Express and General ; it gets higher priority than General, but less than Express

The Cloud RADIUS User is used when you select the EnGenius authentication from Configure > SSID > Captive portal > Authenticated type

Double-click one of the networks on Org-Trees > Configure > EnGenius Auth.> Cloud RADIUS Users to access this screen to view and manage user accounts authenticated using EnGenius Authentication.

The following describes the labels on this screen:

1. Email: Shows the email of the user account.

2. Authorized SSID: This shows the SSID numbers that the user has authorized.

3. Create Date: This shows the date and time that the user was created.

4. Status: This shows whether the user has been blocked or not.

The following describes the functions on this screen:

• Add User: Add users and authorize users to SSIDs.

• Authorize: This allows you to authorize users to SSIDs.

• Delete: Delete users.

• Block: Block users.

• Unblock: Unblock users.

This setting allows you to configure Systems & Protocols in the network at once. This gives you to configure the System setting and apply it to whole Switches in the network. you can access this screen by Configure > Switch settings.

The settings are the same as you configure the individual switches , please refer to below page

Use this screen to configure radio settings for all access points in the network.

Double-click one of the networks on Org-Trees > Configure > Radio Settings.

The settings and options in the Radio Setting page apply to all access points in a network, and you can configure the following settings:

AutoChannel

This option allows users to customize the allowed channels while adhering to country-specific regulations.

When you click “Select DFS Channel,” all DFS channels will be automatically selected from the auto-channel selection list.

When you click “Deselect DFS Channel,” all DFS channels will be automatically deselected from the auto channel selection list.

Exclude DFS

Some use cases may require that Dynamic Frequency Selection (DFS) channels be excluded from the Auto Channel algorithm. DFS channels can be allowed or excluded on the radio settings page.

Since DFS channels can only be used until radar communication is heard, disabling DFS may be useful if the wireless network is in close proximity to a harbor, airport, or weather radar station. Administrators may also want to disable DFS if most local wireless clients do not support DFS channels.

Preferred Scanning Channels (PSC)

With 1200 MHz of spectrum and 59 new 20 MHz channels, a station with a dwell time of 100 ms per channel would require almost 6 seconds to complete a passive scan of the entire band. The standard implements a new efficient process for clients to discover nearby access points (APs). In Wi-Fi 6E, a process called fast passive scanning is being used to focus on a reduced set of channels called preferred scanning channels (PSC). PSCs are a set of 15 20-MHz channels that are spaced every 80 MHz. The APs will set their primary channel to coincide with the PSC so that it can be easily discovered by a client, and clients will use passive scanning in order to just scan PSCs to look for an AP.

PSC Disable: When PSC is disabled, all 6G channels will be available in the interface, allowing users to select any channel freely.

PSC Enable: When PSC(Prefered Scanning Channel) is enabled, channels are grouped into sets of four for easier selection, based on the minimum 80 MHz spacing requirement.

Channel Width

The use of 40 MHz channels on the 2.4 GHz band does not provide for multiple independent channels in multi-AP deployments for 2.4GHz. The recommended setting is 20MHz. To maximize throughput, use 40 MHz for 802.11n and 80 MHz for 802.11ac for 5GHz. Note that higher density deployments should use 20 MHz or 40 MHz channels on 5 GHz.

Tx Power

Using this option, users can set a custom range for Tx power.

The higher the transmission power (Tx power) of the access point, the bigger the coverage of the WiFi signal, so usually maximum power is set for an access point to connect to another access point for WDS or mesh purposes.

However, it might not be the best practice if the access point serves the purpose of being a client access point because usually client devices (notebooks, mobile phones, etc.) might not have the same transmission power to be able to communicate back.

If your enterprise environment is comprised mainly of notebooks and mobile phones, then it is better to turn down your access point transmission power to 15-17dBm on 5G, and 10-12dBm for 2.4G (so the coverage area of 5G and 2.4G is about the same). If you keep the same transmission power of 5G and 2.4G, it also means the signal strength of 2.4G is about 6 dB higher than 5G at the same location. Then the client device might roam from 5G to 2.4G because it detects better signal strength. It is highly recommended to leverage the EnGenius ezWiFiPlanner tool to simulate coverage with different transmission power settings.

Minimum Bit Rate

EnGenius access points can adjust the minimum bit rate for each radio (2.4G and 5G separately). When the minimum bitrate is set, an access point will send out beacons based on the minimum bit rate.

For example, if the bit rate is set to 6Mbps, then those clients with slower than 6Mbps bit rate will not be able to connect to the WiFi and will not slow down other clients' performance. 802.11b max bit rate is 11Mbps, so if 12Mbps is set per radio, then 802.11b clients will not be able to connect to the network.

The other benefit is to help better roaming, because when a client roams to a weaker RSSI signal and causes slower performance, then the access point will be kicked out, and the client will search the available SSIDs again to connect to a stronger signal SSID.

If the value is set too high, then it also means a greater density of access points are required to cover the area with the minimum bit rate. This may potentially cause more channel conflict because the transmission power of the access point remains the same, so the RF coverage area is the same and more RF areas overlap.

Client Limit

This is a hardware limitation, commonly applied to most access points in the market. There can be 254 clients connected to an access point at a maximum (127 clients to each 2.4G and 5G band). To serve more than 127 2.4/5G clients in a space, a higher density of access points must be deployed.

Discard 802.11 a/b/g

This option allows users to discard 802.11 a/b/g devices to use network to prevent the impact of performance on other 802.11ac/ax clients.

Disable 11ax

Some legacy wireless clients are not compatible with 11ax. This option allows legacy equipment to connect with your network as usual, we suggest you disable 11ax in 2.4G of your Radio settings. In this way, you can have equipment working in 5G with better performance and get legacy devices served well in 2.4G.

Disable 11be

Some legacy wireless clients are not compatible with 11be. This option allows legacy equipment to connect with your network as usual.

Disable RTS/CTS

Disabling RTS/CTS can reduce additional signaling overhead and latency, thereby increasing data transmission efficiency, especially in environments with strong signals and minimal interference, such as in directional antennas.

DCS (Dynamic Channel Selection)

Dynamic Channel Selection allows a Wireless Access Point to monitor traffic and noise levels on the channel which is current operating and also keeps watching utilization of other channels with background scanning.

When DCS is enabled and traffic or noise levels of current channel exceed predefined threshold (50%) for a period (15 mins), the AP ceases operating on the current channel and hops to an alternative channel with best utilization in statistics. If you want to schedule the DCS, you could expand the advanced settings and select 2 timeslots in a day or do the DCS every time interval.

When to use it

DCS is useful for the complex and dynamic wireless environment where numerous APs and travel routers broadcast and transmit packets in the same area. It usually comes with high radio interference and the situation changes from time to time. In this case, DCS could be helpful to react for unexpected interference with a short-term mechanism and jump to a cleaner channel to operate.

Client Balancing

After you enable Client Balancing, AP will use information about the state of the network and wireless protocol 802.11V to steer the clients to the best available access point during association. Require firmware v 1.x.20 or above, and only support on ECW220v2/ECW220v3.

Mesh

This option will allow users to enable meshing on the 2.4GHz, 5GHz or 6GHz bands. Auto Pairing will assist in wirelessly connecting (meshing) to an access point (AP) that is not connected to a LAN connection.

Once you enable mesh and click Apply, an Auto Pairing button will appear. The Auto Pairing button will trigger access points that are connected to the internet to scan and mesh with neighboring access points that are not connected to the internet.

How to enable mesh node

1. Locate an AP that is wired and connected to a LAN (i.e., connected to Cloud, Power LED is steady orange).

2. Place the new unwired AP, which is already registered to an organization (Org) and assigned to a network, within 10 meters of the LAN-connected AP.

3. Power on the new unwired AP and the “mesh” LED will begin flashing.

4. Click the Auto Pairing button under Radio Settings in cloud to begin the meshing process. The connected AP will attempt to find and mesh with the new unwired AP.

a. There must be a cloud-connected AP nearby for the new AP to wirelessly connect.

b. All APs must be on the same “network” so that the mesh configuration can be pushed to all

APs in the mesh group.

c. It will take approximately 4-10 minutes for an AP to complete the meshing process due to

firmware upgrade and reboot.

5. Once complete and successful, the mesh LED will be on, and the power LED will be blue on all

mesh-connected APs.

This setting allows you to configure VLAN to all devices in the network at once . Table displays all VLANs have been configure in selected network .

Use this screen to add and delete VLANs for network.

Click Configure > VLAN Settings to access this screen.

The VLAN Settings page contains the following information :

• VLAN ID : VLAN ID.

• NAME : VLAN name.

• Voice VLAN : This shows if VLAN has been assigned to Voice VLAN or not.

• SSID : the SSID that has been assigned the VLAN.

Add VLAN

1. Click Add VLAN button.

2. Input VLAN ID and VLAN Name.

3. Click Apply to complete the settings.

How to Configure Captive Portal

1. Before you begin configuring a captive portal, you need to create a SSID. Navigate to Configure > SSID (If you can't click configure, please make sure you are on network scope).

2. Select one of the SSIDs from the list. If one is not available, please click Add SSID to create one.

3. Navigate to the captive portal and click Enabled and then select the authentication type.

4. Click Apply.

LAN allows you to partition your network into different subnets such that downstream hosts are separated into different broadcast domains based on the VLAN they operate in. VLAN-based network separation can be an effective tool for isolating and identifying different segments of your network and therefore provides an additional layer of security and control. The EnGenius Gateway can have multiple LAN IPs, each of which is the default gateway address on its particular VLAN.

You can access this page through Configure > Gateway > Interface > LAN

There are two modes for the LAN Interface

Hybrid Port

The ESG can support a single Bridge and multiple VLANs. The same LAN port can be added to both a bridge and VLAN simultaneously.

Multiple Bridge

the ESG provides the flexibility to operate in multiple untagged subnets (Bridges) and multiple tagged subnets (VLANs) on the LAN side. If you want to have multi-untagged subnet environments, you can use Multiple bridge mode. However, The same LAN port cannot be added to both a bridge and VLAN simultaneously.

How to configure Multiple untagged subnets on your network

1. Select the "Multiple Bridge"

1. Add another interface and set Bridge mode

1. Verify the Untagged subnets if this is OK

How to Add an Interface

To add a new Interface, click Add Interface at the top right of the LAN table. To modify an existing LAN, click the Interface name in the LAN table.

Addressing

You can click the LAN interface name to access the below screens.

Name: Enter the LAN interface name

IP address: Use this option to enter the IP subnet and IP address of the gateway for the LAN Interface. For example, if the IP subnet is 192.168.100.0/24 and the gateway's IP Address is 192.168.100.1/24, please enter 192.168.100.1/24.

Use VPN: Determines whether the EnGenius Gateway advertises this LAN Interface to site-to-site VPN peers.

Port: select the port to use the LAN Interface.

DHCP

The EnGenius gateway provides a fully-featured DHCP service when configured in Routed mode on the Configure > Gateway > Interface > WAN > Operation mode page. You can enable and configure the DHCP service on each LAN Interface individually, You can access this screen on the Configure >Gateway > Interface > DHCP page.

The configuration options include:

• Client Addressing: Choose Run a DHCP server to enable DHCP services on that particular VLAN

• DNS Servers: DNS servers that the DHCP server will instruct the clients to use

• Reserved IP range: IP ranges that are reserved and therefore will not be assigned to clients.

• Fixed IP List: IP addresses that are allocated to specific devices by MAC address to ensure that these devices always get the same IP address when they make a DHCP request.

Advanced Setting:

• Lease Time: Specify the DHCP address lease time, the default is 1 day. You can select 30 minutes,1 hour, 4 hours, 12 hours, 1 day, and 1 week.

• Additional Options: Specify additional DHCP options sent to the DHCP client by clicking +Add

DHCP Relay

If you want to forward DHCP requests for a configured subnet or VLAN to another DHCP server rather than serving DHCP on the EnGenius Gateway, you can do so by choosing the Relay DHCP to another subnet DHCP server option for Client addressing and entering the IP address of the DHCP server you wish to forward requests to.

The DHCP relay server must be reachable in one of the following three ways:

• The DHCP server is in a local VLAN configured on the EnGenius Gateway

• EnGenius Gateway's DHCP server in all LAN interfaces is disabled.

• The DHCP server is in a subnet for which a static LAN route is configured on the EnGenius Gateway.

Captive Portal

Authentication Type

There are 2 options, Click-through and Custom RADIUS (External)

Click-through: After a client opens and enters a URL on his/her browser, the Client browser will be redirected to a Captive Portal splash page without username/password authentication required. But the client must view and acknowledge the splash page before being allowed to access the network.

Custom RADIUS (External): After a client opens and enters a URL on his/her browser, the client will be redirected to a Captive Portal splash page where username/password authentication is required before being allowed to access the network. An external RADIUS server must be set up to authenticate the client’s username/password. Enter the following settings for your gateway to access external RADIUS servers for authentication. You can configure 2 RADIUS servers for redundancy.

• Server 1: IP address, Port number, and shared secret

• Server 2: IP address, Port number, and shared secret

• NAS ID: For NAS(Network Access Server) ID, please enter an ID for your gateway to access the RADIUS servers specified.

• NAS IP: For NAS(Network Access Server) IP, please enter a VLAN IP address of your gateway for your gateway to access the RADIUS servers specified as the source IP address.

• NAS Port: For NAS(Network Access Server) port, please enter a port number for your gateway to access the RADIUS servers specified as the source TCP port number.

Redirect URL

Select one of the 2 options below to redirect the client after successfully passing the Cut-through splash page or the Custom RADIUS (External) splash authentication page.

Redirect to the original URL: Select this option to cache the initial website from the client during the authentication process and then forward it to the originally targeted web server after the user successfully authenticates.

Redirect users to a new URL: Select this option to redirect users to a pre-designated URL after the user successfully authenticates.

Advanced Setting

Session Timeout: Specify a time limit after which users will be disconnected and required to log in again.

Idle Timeout: Specify a time limit for an idle client after which users will be disconnected and required to log in again.

Walled Garden: This option allows users to define network destinations that users can access before authenticating. For example, your company's website.

Splash Page

With a splash page, you can channel LAN users to see a custom page before they can access the Internet.

You can click here to see the details

This allows you to set networking parameters for your gateway, including WAN1, WAN2 settings, Cellular connection, and DDNS. You can access this page through Configure > Gateway > Interface

Operation mode

Routed

In this mode, the EnGenius Gateway acts as a layer 3 routing gateway between WAN and LAN interfaces. Client outbound traffic to the Internet is source Network Address Translated (NATed) with the gateway’s WAN1/WAN2 IP address. As a layer 3 routing gateway, LAN-to-LAN traffic passing through the gateway can also be bridged or routed and can be controlled by outbound firewall rules as well.

Passthrough

In this mode, the EnGenius Security Gateway acts as a layer 2 bridge that does not perform any routing or network address translation for client outbound traffic for Internet access. This mode is usually used when you want to put the EnGenius Security Gateway between a customer's existing external NAT device and an internal L2/L3 switch. And you want to deploy EnGenius Security Gateway to provide firewall filtering and VPN services without changing the existing IP subnet address planning.

WAN1

EnGenius Security Gateway can support dual WAN(WAN1/WAN2) configurations for dual WAN load balance and redundancy. Below are the WAN1 configuration settings. For the connection type, the Interface can be configured to DHCP to dynamically obtain an IP address or to static IP to manually configure the IP address or to use PPPoE to authenticate the gateway to an Internet Service Provider (ISP)

• Name: the WAN Interface Name

• DHCP: When you select DHCP, the gateway will automatically configure its IP address, subnet mask, and default gateway for the WAN interface.

• PPPoE: Point-to-Point Protocol over Ethernet (PPPoE) is a specification used to authenticate a networking device to an Internet Service Provider (ISP). Selecting PPPoE will allow you to enter the following information:

• Username: Enter the username associated with your ISP. This is a required field.

• Password: Enter the password associated with your ISP. This is a required field.

• DNS Server: you can choose the DNS server from ISP or use Google Public DNS (8.8.8.8) or specify nameservers entered in the Primary DNS and Secondary DNS.

• VLAN id: Enter the VLAN id from 1-4094.

• ISP Bandwidth: you should check with your ISP (Internet Service Provider) for the actual Download/Upload bandwidth. The ISP Bandwidth is used in WAN link utilization and dual WAN outbound sessions load balance calculations.

WAN2

EnGenius Security Gateway can support dual WAN(WAN1/WAN2) configurations for dual WAN load balance and redundancy. To deploy dual WAN configuration, you have to enter the following WAN2 settings. After WAN2 is enabled and settings configured here, the WAN2/P3 port will act as the WAN2 port.

Dual WAN Preference:

Primary WAN Interface: either WAN1 or WAN2 can be selected as the Primary WAN Interface in a dual WAN configuration deployment.

Load Policy:

• Failover: When both WAN1 and WAN2 are up, only the Primary WAN is active for inbound and outbound services. If the Primary WAN is down, automatic WAN failover will occur then the other WAN will take over and become active for services. (PS: currently for inbound Client VPN and Site to Site VPN services, automatic WAN failover is not yet supported. When your Primary WAN is down, for the other WAN to take over Client VPN and Site to Site VPN services, you have to manually reconfigure the other WAN as the new Primary WAN.)

• Load balance: For inbound services, the usage and restriction are the same as Failover. for the client's outbound Internet access traffic sessions, when both WAN1 and WAN2 are up, both WAN1 and WAN2 are used for outbound connections. The session load balance distribution algorithm is based on WRR(Weighted Round Robin) using WAN1/WAN2 upload bandwidth.

Cellular Connection

Cellular networks are high-speed, high-capacity voice and data communication networks with enhanced multimedia and seamless roaming capabilities for supporting cellular devices. With the increase in popularity of cellular devices, these networks are used for more than just entertainment and phone calls. They have become the primary means of communication for finance-sensitive business transactions, emergency services, etc. WAN connectivity options, such as cellular networks, now also serve as a reliable backup internet uplink in the event of a primary uplink failure. You can plug in the USB modern in the EnGenius Gateway and configure the following settings.

• SIM PIN: Enter the Security Code on the SIM to prevent unauthorized use of the card.

• Dial on Demand: Only connect when traffic is sent over the interface.

• Idle timeout: If there is no traffic on the interface for the given minutes, the gateway will disconnect the link.

DDNS

We offer the EnGenius Security Gateway that supports Dynamic DNS (DDNS) service by default. With this feature, users can have a hostname associated specifically with the ESG WAN interfaces. ESG uses Dynamic DNS (DDNS) to update a registered DNS hostname A record automatically each time its Primary WAN IP address changes. This feature is useful because it allows the administrator to configure applications such as client VPN to access the EnGenius Gateway by its hostname which is static instead of an IP address that may change over time. When the Primary WAN is down, EnGenius Security Gateway will use the public WAN IP of the other WAN for DDNS update.

• DDNS Enable: click the button to enable/disable the DDNS service.

• DDNS Providers: Select your DDNS service provider from the pull-down menu, if your DDNS service provider is not in the list, please select Custom

• Username: input your registered username

• Password: input your registered password

• Hostname: input your registered DDNS FQDN hostname

• Enter other required information from your DDNS Service Provider
